SINGLE UNIVERSAL JOINTS-TYPES MA AND ME THESE JOINTS ARE FOR USE ON SHAFTS WITH SPEED UP TO 800 SEC/MIN AND WORKING ANGLE UPTO 25° (powered) OF 35° ( sand operated)   CODE SIZE L E MIN 940A----- MA10 38 12 B-- MA13 45 13 C MA16 52 15 D MA20 62 16 E MA25 74 20 F MA23 85 25 G MA40 108 30 H MA45 120 32 J MA50 132 37 K MA60 155 46 L MA73 190 53 D STANDARD SIZE 'B' MAX STAITC BREZING TORQUE(Nm) ROUND WITH Kway S SQUARE H MAX 10 6 6 - - - 13.5 13 6 8 - - - 20 16 8 10 8 - - 45 20 10 13 11 10 10 60 25 12 16 14 12 12 180 32 16 22 16 16 16 405 40 20 25 22 19 19 860 45 20 30 25 22 22 1250 50 25 35 30 25 25 1790 63 32 45 35 32 32 3400 75 40 55 45 40 40 5300 L E MAX SIZE CODE 44 15 ME10 944A-- 50 16 ME13 B 56 19 ME16 C 84 19 ME20 D 98 26 ME25 E 99 28 ME32 F 108 30 ME40 G 127 36 ME45 H 140 41 ME50 J 172 52 ME63 K 222 69 ME75 L   <<BACK   wiperdrive© copyright. 2002
