| WIPER CHIAN NO. | PITCH | ROLLER DIAMETER | WIDTH BETWEEN INNER PLATES | PIN DIAMETER | PIN LENGTH | INNER PLATE DEPTH | PLATE THICKNESS | ULTIMATE TENSILE STRENGTH | AVERAGE TENSILE STRENGTH | WEIGHT PER METER | |
| P mm | d1 max mm | B1 min mm | d2 max mm | L max mm | Lc max mm | h2 mm | T max mm | Q min kn | QO kN | q KG/M | |
*35SH 40SH 50SH 60SH 80SH 100SH 120SH 140SH 160SH 200SH |
9.525 12.700 15.875 19.050 25.400 31.750 38.100 44.450 50.800 63.500 |
5.08 7.95 10.16 11.91 15.88 19.05 22.23 25.40 28.58 39.68 |
4.77 7.85 9.40 12.57 15.75 18.90 25.22 25.22 31.55 37.85 |
3.58 3.96 5.08 5.94 7.92 9.53 11.10 12.70 14.27 19.85 |
14.8 18.8 22.1 29.2 36.2 43.6 53.5 57.6 68.2 86.6 |
19.9 23.4 31.6 37.7 46.9 57.7 62.2 73.0 93.5
|
9.10 12.00 15.09 18.00 24.00 30.00 35.70 41.00 47.80 60.00
|
2.00 2.03 2.42 3.25 4.0 4.80 5.60 6.40 7.20 6.50 |
14.7 22.4 30.4 44.1 88.2 116.6 158.2 206.0 274.0 506.1
|
18.2 24.8 36.2 50.4 93.0 129.1 175.3 266.5 293.0 562.3 |
0.55 0.82 1.25 1.87 3.10 4.52 6.60 8.30 10.30 19.16 |
