| Wiper Chain No. | Pitch | Chian Lacing | Plate depth | Plate thickness | Pin diameter | Pin length | Ultimate tensile strength | Average tensile strength | Weight per meter |
| P mm | h2 max mm | T max mm | d2 max mm | L max mm | Q min kN | Qo kN | q kg/m | ||
FL644 FL666 FL688 FL844 FL944 FL966 FL122 FL1223 FL1244 |
5.940 5.940 5.940 8.000 9.525 9.525 12.700 12.700 12.700 |
4X4 6X6 8X8 4X4 4X4 6X6 2X2 2X3 4X4 |
4.7 4.7 4.7 6.9 8.7 8.7 8.2 10.2 10.2 |
0.60 0.60 0.60 0.73 1.04 1.00 1.00 2.03 0.70 |
1.85 1.85 1.85 2.31 3.28 3.28 3.58 4.45 4.45 |
6.6 9.3 12.0 7.9 10.4 14.9 7.0 12.8 16.7 |
6.50 9.75 13.00 10.00 21.00 31.00 11.43 20.00 44.00 |
7.8 11.8 15.6 12.1 24.7 36.8 13.6 23.8 52.3 . |
0.31 0.20 0.25 0.25 0.43 0.65 0.19 0.61 0.83 |
