| WIPER CHAIN NO. | WIPER CHAIN NO. | PITCH | ROLLER DIMENSIONS | PIN DIMENSIONS | PLATE DIMENSIONS | WEIGHT PER METER | |||||||
P MM |
d1 max mm | d8 max mm | b1 min mm | b8max mm | d2 max mm | L max mm | Lc max mm | h2 max mm | T max mm | t max mm | q kg/m | ||
BS25-C206B BS25-C218A BS25-C210A BS25-C212A BS25-216A BS30-C206B BS30-C208B BS30-C210A BS30-C212A BS30-C216A
|
C2030W C2040W C2050W C2060W C2080W |
19.05 25.40 31.75 38.10 50.80 19.05 25.40 31.75 38.10 50.80 |
11.91 15.88 19.05 22.23 28.58 9.00 1.91 14.80 18.00 22.23 |
18.3 24.6 31.6 36.6 49.0 18.3 24.6 30.6 37.0 49.0 |
4.00 5.70 7.10 8.50 11.00 4.50 6.10 7.50 9.75 12.00 |
8.0 10.3 13.0 15.5 21.5 9.1 12.5 15.0 20.0 25.2 |
3.28 3.96 5.08 5.94 7.92 3.28 3.96 5.08 5.94 7.92 |
24.0 31.0 39.5 48.8 66.2 26.3 35.6 43.0 58.1 71.9 |
25.6 32.8 41.2 50.5 70.0 29.6 39.5 47.1 62.7 77.3 |
8.20 11.70 15.00 18.00 24.00 7.28 9.60 12.20 15.00 18.60 |
1.30 1.50 2.03 3.25 4.00 1.30 1.50 2.00 3.00 4.00 |
1.50 1.50 2.03 3.25 5.00 1.50 2.00 2.40 4.00 5.00 |
0.52 0.79 1.36 2.19 4.06 0.50 0.83 1.27 2.14 3.55 |
 |
 |
| WIPER CHIAN NO | PITCH | ROLLER DIAMETER | WIDTH BET INNER PLATES | PIN DIMENSIONS | PLATE DIMENSIONS | ULTIMATE TENSILE STRENGTH | AVERAGE TENSILE STRENGTH | |||
| P MM | d1 max mm | d8 max mm | b1 min mm | d2 max mm | L max mm | h2 max m | t/T max mm | Q min kN | Qo kN | |
08BS 12BS 12BS-P26 |
12.70 19.05 19.05 |
8.51 12.07 12.07 |
28.0 26.0 |
7.75 11.68 11.68 |
4.45 5.72 5.72 |
27.0 45.4 43.0 |
10.6 16.0 16.0 |
1.6/13 1.85 1.85 |
18.0 28.9 29.0 |
19.8 31.7 31.9 |
 |
| WIPER CHAIN NO | PITCH | ROLLER DIAMETER | WIDTH BET INNER PLATES | PIN DIMENSIONS | PIN DIMENSIONS | ULTIMATE TENSILE STRENGTH | AVERAGE TENSILE SRENGTH | AVERAGE TENSILE SRENGTH | ||||
| P mm | d1 max mm | d8 max mm | b1 min mm | d2 max mm | L max mm | Lc max mm | h2 max mm | T max mm | Q min kN | Q O kN | Q0 kN | |
| C20508 | 31.75 | 10.16 | 19.05 | 9.4 | 5.08 | 31.8 | 34.0 | 15.0 | 2.03 | 21.8 |
23.9 | 1.52 |
