| WIPER CHIAN NO. | PITCH | ROLLER DIAMETER | WIDTH BETWEEN INNER PLATES | PIN DIAMETER | PIN LENGTH | INNER PLATE DEPTH | PLATES THICKNESS | TRANSVERSE PITCH | ULTIMATE TENSILE STRENGTH | AVERAGE TENSILE STRENGTH | WEIGHT PER METER | |
| P mm | d1 max mm | b1 min mm | d2 max mm | L max mm | Lc max mm | h2 mm | T max mm | P1 mm | Q min kn | QO kN | q kg/m | |
08B-2 12A-2 12AH-2 |
12.70 19.05 19.05 |
8.51 11.91 11.91 |
7.75 12.57 12.57 |
4.45 5.94 5.94 |
31.2 48.8 55.3 |
32.2 50.5 57.1 |
11.8 18.0 18.0 |
1.60 2.42 3.25 |
13.92 22.78 26.11 |
32.0 63.6 63.6 |
38.7 82.1 84.5 |
1.34 2.92 3.71 |
