| Wiper Chain No. | Wiper Chain No | Pitch | Chain Laching | Plate depth | Plate thickness | Pin diameter | Pin length | Ultimate tensile strength | Average tensile strength | Weight per meter |
| P mm | h2 max mm | T max mm | d2 max mm | L max mm | Q min kN | Q0 kN | q kg/meter | |||
LH0822 LH0823 LH0834 LH0844 LH0846 LH0866 LH0888 LH1022 LH1023 LH1034 LH1044 LH1046 LH1066 LH1088 LH1222 LH1223 LH1234 LH1244 LH1246 LH1266 LH1288 LH1622 LH1623 LH1234 LH1644 LH1646 LH1666 LH1688
|
BL422 BL423 BL434 BL444 BL446 BL466 BL488 BL522 BL523 BL534 BL544 BL546 BL566 BL588 BL622 BL623 BL634 BL644 BL646 BL666 BL688 BL822 BL823 BL834 BL844 BL846 BL866 BL888
|
12.7
15.875
19.05
25.4
|
2X2 2X3 3X4 4X4 4X6 6X6 8X8 2X2 2X3 3X4 4X4 4X6 6X6 8X8 2X2 2X3 3X4 4X4 4X6 6X6 8X8 2X2 2X3 3X4 4X4 4X6 6X6 8X8
|
12.07
15.09
18.11
24.13
|
2.08
2.44
3.3
4.09 |
5.09
5.96
7.94
9.54
|
11.05 13.16 17.40 19.51 23.75 27.99 36.45 12.90 15.37 20.32 22.78 27.74 32.69 42.57 17.37 20.73 27.43 30.78 37.49 44.20 57.61 21.34 25.48 33.76 37.90 46.18 54.46 71.02
|
22.2 22.2 33.4 44.5 44.5 66.7 89.0 33.4 33.4 48.9 66.7 66.7 100.1 133.4 48.9 48.9 75.6 97.9 97.9 146.8 195.7 84.5 84.5 129.0 169.0 169.0 253.6 338.1
|
27.6 27.6 41.4 56.0 56.0 81.7 109.4 43.1 43.1 65.6 84.5 84.5 125.1 169.5 63.6 63.6 102.8 120.9 120.9 190.8 238.8 108.2 108.2 170.0 214.6 214.6 324.5 432.5
|
0.64 0.84 1.12 1.28 1.60 1.92 2.56 0.88 1.10 1.50 1.80 2.20 2.65 3.50 1.45 1.80 2.50 2.90 3.60 4.30 5.80 2.20 2.70 3.80 4.30 5.40 6.50 8.60 |
| Wiper chian No | Wiper Chain No. | Pitch | Chian lacing | Plate depth | Plate thickness | Pin diameter | Pin length | Ultimate tensile strength | Average tensile strength | Weight per meter |
| P mm | h2 max mm | T max mm | d2 max mm | L max mm | Q min KN | Q0 KN | q kg/m | |||
LH2022 LH2023 LH2034 LH2044 LH2046 LH2066 LH2088 LH2422 LH2423 LH2434 LH2444 LH2446 LH2466 LH2488 LH2822 LH2823 LH2834 LH2844 LH2846 LH2866 LH2888 LH3222 LH3223 LH3234 LH3244 LH3246 LH3266 LH3288 LH4022 LH4023 LH4034 LH4044 LH4046 LH4066 LH4088
|
BL1022 BL1023 BL1034 BL1044 BL1046 BL1066 BL1088 BL1222 BL1223 BL1234 BL1244 BL1246 BL1266 BL1288 BL1422 BL1423 BL1434 BL1444 BL1446 BL1466 BL1488 BL1622 BL1623 BL1634 BL1644 BL1646 BL1666 BL1688 BL2022 BL2023 BL2034 BL2044 BL2046 BL2066 BL2088 |
31.75
38.10
44.45
63.50
50.80 |
2X2 2X3 3X4 4X4 4X6 6X6 8X8 2X2 2X3 3X4 4X4 4X6 6X6 8X8 2X2 2X3 3X4 4X4 4X6 6X6 8X8 2X2 2X3 3X4 4X4 4X6 6X6 8X8 2X2 2X3 3X4 4X4 4X6 6X6 8X8
|
30.18
36.20
42.24
48.26
60.33
|
4.90
5.77
6.55
7.52
9.91
|
11.11
12.71
14.29
14.29
17.46
23.81 |
25.37 30.33 40.23 45.19 55.09 65.00 84.81 29.62 35.43 47.07 52.88 64.52 76.15 99.42 33.55 40.16 53.37 59.97 73.18 86.39 112.8 39.01 46.58 61.72 69.29 84.43 99.57 129.84 51.74 61.70 81.61 91.57 111.48 131.39 171.22
|
115.6 115.6 182.4 231.3 231.3 347.0 462.6 151.2 151.2 244.6 302.5 302.5 453.7 605.0 191.3 191.3 315.8 382.6 382.6 578.3 765.1 289.1 289.1 440.4 578.3 578.3 857.4 1156.5 433.7 433.7 649.4 867.4 867.4 1301.1 1734.8 |
150.8 150.8 231.6 291.4 291.4 430.3 555.1 192.0 192.0 315.9 381.1 381.1 543.6 726.0 225.7 225.7 372.6 451.2 451.2 682.4 902.8 341.1 341.1 519.6 680.4 680.4 1000.7 1364.6 511.7 511.7 766.2 1023.5 1023.5 1535.2 2046.5
|
3.40 4.30 6.00 6.90 8.60 10.30 13.80 4.6 5.8 8.1 9.3 11.6 13.9 18.6 6.1 7.6 110.6 12.2 15.2 18.2 24.3 8.0 10.0 14.0 16.0 20.0 24.0 32.0 15.8 19.8 27.7 31.6 39.5 47.4 63.2
|
