| 3939 LUMBER CONVEY CHAIN |
 |
 |
| Chain No. | Pitch | Roller dia | Width bet inner plates | Pin dimensions | Plate dimensions | Plate thick | Ultimate tensil strength | Average tensil strength | Weight per meter | |||||
| p | d1 max | b1 min | d2 max | L max | h2 max | d3 max | d4 max | J max | K max | T max | Q min | Q0 | q | |
| mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | KN | KN | KN | |
3939-B4 3939-B21 3939-B23 3939-B24 3939-B40 3939-B43 3939-B44 |
203.2 203.2 203.2 203.2 203.2 203.2 203.2 |
23.00 23.00 23.00 23.00 23.00 23.00 23.00 |
27.00 27.00 27.00 27.00 27.00 27.00 27.00 |
11.1 11.1 11.1 11.1 11.1 11.1 11.1 |
49.0 49.0 49.0 49.0 49.0 49.0 49.0 |
28.58 28.58 28.58 28.58 28.58 28.58 28.58 |
7.2 7.2
7.2 7.2 |
7.2
10.3 7.2 10.3 10.3 10.3 |
38.138.1
38.1 38.1 |
101.6
92.1 101.6 101.6 92.1 101.6 |
4.0 4.0 4.0 4.0 4.0 4.0 4.0
|
115.58 115.58 115.58 115.58 115.58 115.58 115.58 |
136.5 136.5 136.5 136.5 136.5 136.5 136.5 |
2.45 2.45 2.45 2.45 2.45 2.45 2.45 |
